Minnkota Power Cooperative

Project Tundra

The Project Tundra, spearheaded by Minnkota Power Cooperative in partnership with Mitsubishi Heavy Industries and Kiewit, is a large-scale CO₂ capture and storage initiative sited at the Milton R. Young Station, a lignite-fired power plant near Center in Oliver County, North Dakota. The project aims to capture up to 4 million metric tons of CO₂ annually using advanced amine-based post-combustion technology. Storage will occur in deep geologic formations, specifically the Broom Creek and Deadwood Formations. Project Tundra has earned regulatory approval of Class VI storage permits from the North Dakota Industrial Commission, and allocation of federal support including up to $350 million in DOE funding and $250 million in low-interest loans from North Dakota’s Clean Sustainable Energy Authority (CSEA). The project design includes up to three Class VI injection wells. Construction is expected to begin in 2024 with completion by 2028.

City

New Salem

Country

United States of America

Region

us

Gov funding

$48,611,271

Overview

Full Project Overview

All key information and technical data related to this project

Overview

Project name:
Project Tundra
Project categories:
class_vi
City:
New Salem
County:
Oliver
State:
North Dakota
Country:
United States of America
Region:
United States
Government funding:
$48,611,271
Applicant name:
Minnkota Power Cooperative, Inc.
Status:
Permitted
Well applications:
5
Injection rate (Mt/year):
10,100,000
Total storage capacity (Mt):
200,000,000
Leased acres:
48,678
Announcement date:
2021-11-21
Data

Wells

Data for injection rates, perforation, and other well-related metrics.

IIW-N

Injection rate (Mt / year)
1,768,060
Injection years
20
Wellbore schematic
Well class
Injector

IIW-S

Injection rate (Mt / year)
4,342,405
Injection years
20
Well class
Injector

Unity 1

Injection rate (Mt / year)
2,054,950
Injection years
20
Well class
Injector

McCall 1

Injection rate (Mt / year)
1,186,250
Injection years
20
Well class
Injector

Liberty

API
33065000200000
Injection rate (Mt / year)
1,819,890
Injection years
20
Well class
Injector
Permit date
2020-09-08

NRDT-1

API
33065000280000
Well class
Monitor

J-LOC 1

API
33065000190000
Well class
Stratigraphic
Permit date
2020-05-14

Freeman 1

API
33-065-00029-00-00
Well class
Monitor
Permit date
2025-01-17
Data

Geology

Subsurface data for carbon storage.

Broom Creek

Krw @ Sgr
1
KrCO₂ @ Swr
0.9
Water exponent
6
CO₂ exponent
6
Residual gas saturation
0.1
Model
Corey-Brooks

Black Island

* Graph available
Gross thickness (ft)
118
Depth TVD (ft)
9,427
Porosity
5.5%
Permeability (md)
9.8
Temperature (°F)
181
Pressure (psia)
4,582
Salinity (ppm)
256,000
Krw @ Sgr
1
KrCO₂ @ Swr
1
Water exponent
5
CO₂ exponent
5
Model
Corey-Brooks
Relative Permeability Graph

Deadwood

Gross thickness (ft)
64
Depth TVD (ft)
9,773
Porosity
3.81%
Permeability (md)
31.7
Krw @ Sgr
1
KrCO₂ @ Swr
1
Water exponent
6
CO₂ exponent
6
Model
Corey-Brooks
Download

Project Documents

Technical, design, and planning materials outlining the project’s scope, development approach, and implementation details.

Download

Permitted Documents

Official approval, consent, and compliance documents issued by authorities, confirming the project is authorised to proceed.
