classVIDecatur Campus
Company Logo

Archer Daniels Midland

Decatur Campus

The ADM Decatur carbon storage project is a bioenergy carbon capture and storage (BECCS) system located at Archer Daniels Midland’s ethanol production complex in Decatur, Illinois, injecting captured fermentation CO₂ into deep saline formations within the Illinois Basin. The project includes two phases: the Illinois Basin–Decatur Project (IBDP) demonstration phase and the commercial-scale Illinois Industrial Carbon Capture and Storage (IL-ICCS) project operating under EPA Class VI permitting and Subpart RR MRV requirements. CO₂ captured from ethanol fermentation is compressed and injected into the Mount Simon Sandstone, a regionally extensive saline reservoir overlain by the Eau Claire shale confining system, approximately ~7,000 ft depth. The project history began with site characterization and testing in the late 2000s, followed by injection during the IBDP demonstration phase from 2011–2014, where approximately 1 million tonnes of CO₂ were injected to validate large-scale saline storage and monitoring techniques. After successful demonstration, ADM expanded to the IL-ICCS commercial phase, initiating injection in 2017 with a designed capture capacity of approximately ~1 million tonnes CO₂ per year, making it one of the first large-scale BECCS deployments globally.

City

Decatur

Country

United States of America

Region

us

Gov funding

$165,000,000

Overview

Full Project Overview

All key information and technical data related to this project

Overview

Project name:
Decatur Campus
Project categories:
class_vi
City:
Decatur
County:
Macon
State:
Illinois
Country:
United States of America
Region:
United States
Government funding:
$165,000,000
EPA region:
5
Applicant name:
Archer Daniels Midland
Status:
Permitted
Well applications:
4
Injection rate (Mt/year):
1,000,000
Total storage capacity (Mt):
6,570,000
Announcement date:
2014-10-03
News

Related News

Explore recent news and developments connected to this project.

Date
Article title
Source
2024-10-02
ADM pauses CO2 injection at carbon capture storage site after finding potential leak
2008-01-04
ADM, MGSC and ISGS Announce Carbon Sequestration Project
2024-11-13
ADM carbon sequestration project violated Safe Drinking Water Act, per EPA
2021-05-19
ADM Announces Successful Completion of One Million Metric Ton Carbon Capture and Storage Project
2014-09-26
U.S. EPA Approves Carbon Sequestration Permit in Decatur, Illinois
2025-05-21
Bill banning carbon sequestration near Mahomet Aquifer clears General Assembly
2007-12-19
DOE Awards $66.7 Million for Large-Scale Carbon Sequestration Project; Ethanol Plant the CO2 Source
2011-08-24
Large-Scale Industrial Carbon Capture, Storage Plant Begins Construction
2011-11-21
Large-scale CO2 injection test begins in Illinois
2017-04-20
ADM starts commercial-scale CCS at Decatur ethanol plant
2026-01-06
Decatur To Host Community Forum Amid Carbon Capture Concerns
Data

Wells

Data for injection rates, perforation, and other well-related metrics.

CCS #1

Injection rate (Mt / year)
365,000
Injection years
3
Wellbore schematic
Perforation intervals (feet)
6283 - 6357
Well class
Injector

CCS #2

Injection rate (Mt / year)
1,095,000
Injection years
5
Wellbore schematic
Perforation intervals (feet)
6020 - 6190
Well class
Injector

Proposed CCS #3

Injection rate (Mt / year)
1,204,500
Injection years
12
Well class
Injector

VVW #2

Well class
Monitor

VVW #1

Well class
Monitor
Data

Geology

Subsurface data for carbon storage.

Upper Mt. Simon

Gross thickness (ft)
406
Depth TVD (ft)
5,065
Porosity
11%
Permeability (md)
66
Datum Depth (ft)
6,345
Temperature (°F)
120
Pressure (psia)
3,205
Salinity (ppm)
196,000
Krw @ Sgr
1
KrCO₂ @ Swr
0.85
Water exponent
2.1
CO₂ exponent
2.1
Residual water saturation
0.33
Residual gas saturation
0.1
Model
Corey-Brooks

Middle Mt. Simon

Gross thickness (ft)
470
Depth TVD (ft)
5,503
Porosity
9%
Permeability (md)
2.5

Lower Mt. Simon

* Graph available
Gross thickness (ft)
629
Depth TVD (ft)
6,053
Porosity
17%
Permeability (md)
60
Krw @ Sgr
1
KrCO₂ @ Swr
0.75
Water exponent
2
CO₂ exponent
2
Residual water saturation
0.6
Model
Corey-Brooks
Relative Permeability Graph
Download

Project Documents

Technical, design, and planning materials outlining the project’s scope, development approach, and implementation details.

Download

Permitted Documents

Official approval, consent, and compliance documents issued by authorities, confirming the project is authorised to proceed.

Permitted files
04-11-2024_ADM_Decatur_Campus_CCS_1_-_Area_of_Review__Corrective_Action_Plan.pdf
04-11-2024_ADM_Decatur_Campus_CCS_1_-_Emergency__Remedial_Response_Plan.pdf
04-11-2024_ADM_Decatur_Campus_CCS_1_-_Financial_Responsibility.pdf
04-11-2024_ADM_Decatur_Campus_CCS_1_-_Injection_Well_Construction_Plan.pdf
04-11-2024_ADM_Decatur_Campus_CCS_1_-_Permit.pdf
04-11-2024_ADM_Decatur_Campus_CCS_1_-_Plugging_Plan.pdf
04-11-2024_ADM_Decatur_Campus_CCS_1_-_Post-Injection_Site_Care_and_Site_Closure_Plan.pdf
04-11-2024_ADM_Decatur_Campus_CCS_1_-_Summary_of_Requirements.pdf
04-11-2024_ADM_Decatur_Campus_CCS_1_-_Surveillance_Plan.pdf
04-11-2024_ADM_Decatur_Campus_CCS_1_-_Testing__Monitoring_Plan.pdf
04-11-2024_ADM_Decatur_Campus_CCS_2_-_Area_of_Review__Corrective_Action_Plan.pdf
04-11-2024_ADM_Decatur_Campus_CCS_2_-_Emergency__Remedial_Response_Plan.pdf
04-11-2024_ADM_Decatur_Campus_CCS_2_-_Financial_Responsibility.pdf
04-11-2024_ADM_Decatur_Campus_CCS_2_-_Injection_Well_Construction_Plan.pdf
04-11-2024_ADM_Decatur_Campus_CCS_2_-_Permit.pdf
04-11-2024_ADM_Decatur_Campus_CCS_2_-_Plugging_Plan.pdf
04-11-2024_ADM_Decatur_Campus_CCS_2_-_Post-Injection_Site_Care_and_Site_Closure_Plan.pdf
04-11-2024_ADM_Decatur_Campus_CCS_2_-_Stimulation_Program.pdf
04-11-2024_ADM_Decatur_Campus_CCS_2_-_Summary_of_Requirements.pdf
04-11-2024_ADM_Decatur_Campus_CCS_2_-_Surveillance_Plan_Appendices.pdf
04-11-2024_ADM_Decatur_Campus_CCS_2_-_Surveillance_Plan.pdf
04-11-2024_ADM_Decatur_Campus_CCS_2_-_Testing__Monitoring_Plan.pdf
06-20-2024_ADM_Decatur_Campus_CCS_2-_MRV_Plan.pdf
06-20-2024_ADM_Decatur_Campus_CCS_3_-_Cost_Estimation.pdf
06-20-2024_ADM_Decatur_Campus_CCS_3_-_Emergency__Remedial_Response_Plan.pdf
06-20-2024_ADM_Decatur_Campus_CCS_3_-_Narrative__Area_of_Review__Corrective_Action_Plan.pdf
06-20-2024_ADM_Decatur_Campus_CCS_3_-_Plugging_Plan.pdf
06-20-2024_ADM_Decatur_Campus_CCS_3_-_Post-Injection_Site_Care_and_Site_Closure_Plan.pdf
06-20-2024_ADM_Decatur_Campus_CCS_3_-_Preoperational_Testing_Plan.pdf
06-20-2024_ADM_Decatur_Campus_CCS_3_-_Testing__Monitoring_Plan.pdf
